📋 Overview & Basic Information
Certification
CE, ISO13485
LCD Display
With LCD Display
Technology
Dual Shockwave Machine
Shockwave Frequency
1 - 21Hz
Ultrasound Frequency
1 MHz
Bullet Lifespan
3 Million Shots
Transmitters
13 PCS (Pain, Spine, Fascia)
Screen
8-Inch Touch Screen
Production Capacity
500 Pieces/Month
Dual Shockwave Ultrasound Physiotherapy System
Pneumatic Ballistic Shock Wave + Ultrasound is a dual-modality physical therapy system that integrates high-energy pneumatic shockwave pulses with deep-penetrating therapeutic ultrasound. This combined approach is designed for musculoskeletal rehabilitation, pain relief, and tissue regeneration.
🔬 Technology Principle
Pneumatic Shockwave Therapy
The system delivers high-pressure pneumatic pulses that transmit mechanical energy deep into muscles, tendons, and connective tissues. Key biological effects include:
- Micro-circulation enhancement: Stimulates new capillary formation and speeds elimination of metabolic waste.
- Collagen remodeling: Accelerates fibroblast activity for tissue elasticity.
- Pain pathway interruption: Inhibits nociceptors and increases pain-tolerance thresholds.
- Mechanical separation of adhesions: Loosens fibrosis and chronic scar tissues.
Therapeutic Ultrasound Technology
Utilizes high-frequency mechanical vibrations to produce thermal and non-thermal effects:
- Thermal: Increases local temperature, promotes blood flow, and relaxes muscle tension.
- Non-Thermal: Micro-massage at molecular level, reduction of edema, and enhanced cell permeability.
📊 Product Attributes
| Model |
INTELECT PULS 50 |
| Technology | Pneumatic Shockwave + Therapeutic Ultrasound |
| Shockwave Intensity | 0.5 - 10 Bar (0.1 Bar regulation) |
| Shockwave Frequency | 1 - 21 Hz (1 Hz regulation) |
| Bullet Lifespan | 3 million shots |
| Shockwave Transmitters | 13 pcs total |
| Pain Management Heads | 6 pcs (D35/D25/D20/D15/D10/D6) |
| Ultrasound Intensity | 0.2-3 W/cm² |
| Ultrasound Frequency | 1 MHz continuous; 1-10 Hz pulse mode |
| Control Interface | 8-inch Touch-screen |
🎯 Application Scope
Shockwave Applications
- Sports injuries recovery
- Tennis/Golfer's elbow
- Plantar fasciitis & Heel pain
- Erectile vascular dysfunction (ED)
- Cellulite reduction
Ultrasound Applications
- Chronic strains & sprains
- Bursitis & Myositis
- Osteoarthritis
- Tissue edema & Inflammation
- Soft tissue stiffness
⭐ Core Features
- Dual Therapy Integration: Complete musculoskeletal rehabilitation in one console.
- 13 Professional Transmitters: Specialized heads for pain, spine, and fascia.
- High Precision System: Stable output ensures consistent powerful pulses.
- Smart Parameter Preset: Pre-programmed protocols for different body parts.
- Long-Life Technology: 3 million shots per bullet reducing maintenance costs.
Contraindications
Treatment should be avoided in the following cases:
- Active infections or open wounds
- Presence of pacemakers or electronic implants
- Pregnancy (specifically for ultrasound)
- Hemophilia or coagulation disorders
- Malignant tumors in the treatment area
- Areas with metal implants after fracture
Frequently Asked Questions
What is the advantage of combining shockwave and ultrasound?
Shockwave therapy excels at breaking down adhesions and stimulating cellular repair, while ultrasound provides deep thermal effects and reduces inflammation, leading to faster recovery.
How long does a typical treatment last?
Treatment time is adjustable between 1-20 minutes depending on the specific condition and the body part being treated.
Is the treatment painful?
Pneumatic shockwave therapy involves high-pressure pulses; patients may feel some intensity, but parameters can be adjusted for comfort. Mild soreness post-treatment is normal.
How many shockwave transmitters are included?
The system includes 13 professional transmitters: 6 for pain management, 3 for spine-specific therapy, and 4 for fascia work.
What is the maintenance requirement for the handpiece?
The device uses long-life bullet technology designed for 3 million shots, significantly reducing the frequency of component replacement.
Can this device be used for ED treatment?
Yes, the pneumatic shockwave technology is an effective non-invasive application for erectile vascular dysfunction and improving circulation.
